MegaMax

No reviews
Description

MegaMax®


Are you tired of needing multiple ladders for one task? Simplify your climbing needs by getting the right ladder. Whether you need a ladder in the home or on the go, the Little Giant® MegaMax® is ideal to help you get the job done efficiently.


Multi-Position Ladder

Unlike traditional ladders that only offer one position, the MegaMax is a multi-position, articulating ladder. It allows you to set up in A-frame, extension, 90-degree, staircase and trestle-and-plank* configurations with ease.


Easy to Transport

It’s time to get rid of your old, heavy ladder. Made from sturdy, lightweight aluminum, the MegaMax is easy to carry. Plus, its Tip & Glide™ Wheels make transportation easier than ever.


Rock Lock® Adjusters

When adjusting your ladder, use the MegaMax Rock Lock® adjusters to seamlessly transition your ladder from position to position.


AirDeck® Ports

With its AirDeck® ports, you can attach the Little Giant AirDeck to your ladder, giving you a sturdy workspace.


Rating

Meeting or exceeding all OSHA and ANSI standards, the MegaMax is rated to hold 300 lbs. in all configurations; and in A-frame, it will hold 300 lbs. on both sides.


*Plank not included.

Specs

Specifications

Model Number 14417-001
ANSI Duty Rating Type IA - Extra Heavy Duty
Weight Capacity 300 lbs.
Product Material Aluminum
Warranty Limited Lifetime
Product Weight 34 lb
Country of Origin China
Storage Depth 8 in
Storage Height 55 in
Storage Width at Base 2 ft
Feet Standard non-marring (snap-on)
Spreader System Hinge Lock

Features

90° Position Yes
Tip & Glide Wheels™ Yes
V-Bar No
Ratchet Levelers No
Ground Cue No
Air Deck Ports Yes
Claw No
Scaffolding Position Yes

A-Frame

Ladder Size 15 ft
Palm & Hinge Lock System Plastic / Triple Locking Hinge
Height Adjusting Lock Extra Heavy Duty Lock Tab
Inside Clear Width 1.04 ft
Inner Rung Depth 1.4 in
Outer Rung Depth 1 in
Rung Size Double Section 3 in
Top Width 1.5 ft
Highest Standing Level
Maximum Footprint 5.19 ft
Max Reach 12.25 ft

Extension

Extension Lock Extra Heavy Duty Lock Tab
Extension Min Reach 8.92 ft
Extension Minimum Working Length 8.92 ft
Extension Maximum Working Length 14.92 ft
Extension Max Reach 18.08 ft
Extension Total Length of Sections 17.17 ft


Shipping Specifications

Ship length 4.67 ft
Ship Width 2.08 ft
Ship Height 8 in
Ship Weight 41 lb

YOU MAY ALSO LIKE

FIND ACCESSORIES FOR YOUR LADDER

ACCESSORIES
See All
FAQs
What size ladder do I need?

Size refers to the ANSI definition of length. ANSI states that the size is defined by the combined length of all rail sections, with a tolerance of +/-3” on each section. Note, this does not take into account any overlap between sliding sections like those on an extension or multi-purpose ladder. This can cause a disparity in the size of the ladder versus the actual height. To determine which ladder you need, Little Giant recommends you reference maximum reach height instead of size.

What is Duty Rating?

The terminology for ladder duty ratings, grades, and types can sometimes be confusing. The ladder's duty rating is the maximum safe load capacity of that ladder according to ANSI standardsThere are 3 types of ratings that Little Giant offers:

Type I - Made to handle everyday projects. Has a load capacity of 250 lbs.

Type IA- Designed with durability and regular use in mind. Has a load capacity of 300 lbs.

Type IAA- Built for professional performance and rugged use. Has a load capacity of 375 lbs.

What is the difference between SIZE and MAXIMUM REACH HEIGHT?

Ladder specifications can be confusing due to safety regulation requirements. According to ANSI (American National Standards Institute), the ladder size is defined as the total length of each section and does not account for overlap on extension ladders. As a result, the overlapping sections reduce the total length of the ladder. When purchasing any ladder customers should pay particular attention to the maximum reach to ensure the correct product for the job.

Where Can I Purchase Replacement Parts For My Little Giant Ladder?

Little Giant Ladders offers replacement parts for products manufactured by Little Giant Ladders only. Please contact Customer Service at 1 (800) 453-1192 or shop online at https://www.littlegiantladders.com/pages/ladder-parts.

When ordering replacement parts, you will need to provide the Little Giant Ladder Model Number and Mark Number or a description of the part you need.
